In 2013, the Sydney Opera House embarked on a decade of renewal ahead of its 50th anniversary in 2023. The most ambitious project was the renewal of its largest internal venue, the Concert Hall, a world-renowned, space and one of the most architecturally significant interiors of the Sydney Opera House.

We worked with ARM Architecture to upgrade the Concert Hall to offer a world-leading performance experience for artists and audiences. We also improved access for people with mobility needs and provided a more flexible and safer working environment for staff behind the scenes.

To achieve this transformation, we collaborated with the architects and acoustic consultants Müller-BBM in reviving the venue’s acoustic capability, increased lifting capacity with a new theatrical rigging system and improved fire safety and access to the venue for all abilities by designing a lift shaft to fit within the constraints of a heritage building.

Few buildings define a nation more than the Sydney Opera House. For half a century, the Sydney Opera House has played a role in defining Sydney, its culture and society. It has also played a defining role for our firm, establishing our Australian presence when our founder, Ove Arup, was engaged in the design in the 1950s. Working on the Concert Hall’s renewal was a chance to continue that legacy.

Reviving acoustic capabilities and enhancing fire safety

Over the past 50 years, acoustic design practices have evolved and new technologies have emerged. Müller-BBM’s design replaced the Concert Hall’s existing acrylic ‘donuts’ above the stage with new state-of-the-art acoustic ‘petal’ reflectors. We designed the structure to support a rigging system in the ceiling to hold the petals above the performers, providing an improved listening experience for artists and audiences. The system is capable of retracting in a fire to avoid obstructing the fire suppression systems.

The significant changes in the project were achieved without compromising the fire safety of the hall. Our fire engineering team included enhancements to fire separation and smoke control within the constraints of the existing building ensuring the safety of patrons.

Watch our documentary House Proud to learn more about the building and our enduring relationship with the Sydney Opera House.

Theatre design adaptable for global performances

Today, global performances from musicians, artists and circus acts come with complex equipment and props. To attract these performances to the Sydney Opera House, the Concert Hall’s ceiling capacity to hang equipment needed to be increased to meet the demands of modern shows.

We expanded the area of roof where the air conditioning system was previously and designed a winch room with over 140 new winches weighing 400 tonnes. This is supported by a steel ceiling frame made up of a complex network of over 2,500 elements. We strengthened each element, mapping weld lengths and cross-checking members, to ensure over 40 tonnes of equipment could be suspended from any section of the Concert Hall’s ceiling – a 60 per cent increase in the loading capacity.

Sydney Symphony Orchestra acoustic testing Concert Hall Sydney Opera House © Daniel Boud
Acoustic diffusion panels, Concert Hall Sydney Opera House © Daniel Boud
Concert Hall, Sydney Opera House © Lisa Maree Williams, Getty Images for Sydney Opera House

Improving accessibility with creative design

Everyone should have access to the arts; however, accessibility wasn’t a design norm 50 years ago. Previously, wheelchair users, the elderly and those unable to access the Concert Hall’s northern foyer to enjoy the harbour views without climbing the side foyer staircase. Our challenge was to improve accessibility and design a lift shaft in a complex heritage structure.

The Concert Hall’s structure is made from long-spanned concrete beams, which are challenging to cut through for a lift shaft without anything to support them once cut. Together with ARM Architecture, we created a solution by combining the lift shaft and the existing northern foyer’s staircase. The lift provides access to every floor of the building and is tucked away in the corner providing uncrowded access without taking away from the northern foyer’s elegant design.

Partners & collaborators

ARM Architects | Müller-BBM
